C45 Plug-in Needle
Introduction
- Model: C45
- Material: Copper
- Surface: Outer tin plating
- Application: Suitable for the connection of the wires in contribution equipment and power supply cables with electronic apparatus, adopting copper tube pressing. Imported C45 plug-in needle, adopted Copper tube, and coatedin.
Specification
The following table is the latest size. These are the regular sizes.
If you need more size, please contact us.
| Item | D±0.3 (mm) | d±0.3 (mm) | L±1.5 (mm) | L1±1 (mm) | B±0.3 (mm) | Thickness (mm) |
|---|---|---|---|---|---|---|
| Other Size | Please contact sales | |||||
| A Grade C45-4 | 4.8 | 3.2 | 25 | 10 | 4.5 | 0.8 |
| A Grade C45-62 | 6 | 4 | 27 | 10.3 | 4.8 | 1 |
| A Grade 45-10 | 7.5 | 5.1 | 32 | 12.5 | 6.5 | 1.2 |
| A Grade 45-16 | 8.5 | 6 | 34 | 13.5 | 6.8 | 1.25 |
| A Grade 45-25 | 10 | 7.3 | 36 | 14 | 6.8 | 1.35 |
| A Grade 45-35 | 11 | 8.2 | 38 | 14.5 | 6.8 | 1.4 |
| A Grade 45-50 | 13 | 10 | 42 | 15 | 6.8 | 1.5 |
| A Grade 45-70 | 16 | 12 | 49 | 16 | 7 | 2 |
| A Grade 45-95 | 18 | 14 | 55 | 20 | 7 | 2 |
| B Grade 45-10 | 6.5 | 5.1 | 32 | 12.5 | 6.5 | 0.7 |
| B Grade C45-16 | 8 | 6.4 | 34 | 13.5 | 6.8 | 0.8 |
| B Grade C45-25 | 9 | 7.2 | 36 | 14 | 6.8 | 0.9 |
| B Grade C45-35 | 10.5 | 8.5 | 38 | 14.5 | 6.8 | 1 |
| B Grade C45-50 | 12.5 | 10.1 | 42 | 15 | 6.7 | 1.2 |
| Other Size | Please contact sales |
