DT-G-S Copper Crimp Lug (Long Crimp Tube)
Introduction
- Title: DT-G Copper Crimp Lug (Long Crimp Tube)
- Model: DT-G
- Material: Copper
- Surface: Natural/Tin Plated
Specification
The following table is the latest size. These are the regular sizes.
If you need more size, please contact us.
| Item | D (mm) | d (mm) | L (mm) | L1 (mm) | C (mm) | (W) (mm) | S (mm) |
|---|---|---|---|---|---|---|---|
| Other Size | Please contact sales | ||||||
| DTG-50S | 13 | 10.3 | 115 | 25 | 70 | 19 | 2.7 |
| DTG-70S | 16 | 12.3 | 120 | 25 | 70 | 23 | 3.7 |
| DTG-95S | 18 | 14.3 | 125 | 25 | 70 | 26 | 3.7 |
| DTG-120S | 19 | 15.2 | 130 | 25 | 70 | 28 | 3.8 |
| DTG-150S | 22 | 17.2 | 145 | 35 | 80 | 32 | 4.8 |
| DTG-185S | 24 | 19.2 | 150 | 35 | 80 | 35 | 4.8 |
| DTG-240S | 26 | 21.2 | 155 | 35 | 80 | 38 | 4.8 |
| DTG-300S | 31 | 24.2 | 170 | 35 | 80 | 45 | 6.8 |
| DTG-400S | 34 | 26.2 | 175 | 35 | 80 | 49 | 7.8 |
| DTG-500S | 38 | 30.2 | 190 | 35 | 80 | 55 | 7.8 |
| Other Size | Please contact sales |
